PA6 GF 30
PA GF 30

PA6 GF30 (A1000F, A1011F) for Engineering Plastics

PA 6 GF30 is a 30 % glass fiber reinforced polyamide.

The mechanical properties, dimensional stability, heat resistance, and aging resistance of PA are significantly improved, and the fatigue strength is 2.5 times that of enhancement when 30% glass fiber is added to PA. At the same time, PA6 GF30 is the most widely used product in various industries. Engineering plastic products can meet the requirements of industry and daily usage.

Typical Application of PA6 GF30 (A1000F)

Enhanced grade PA6 gf30 is workable for high-strength, high-wear-resistant structural parts, mainly used in machinery, vehicles, electronic and electrical, textiles, and sports equipment.

Such as the exterior mirror and door handle of the automobile as well as the engine cover.

Processing Detail of PA6 GF30 (A1000F)

Processing Detail of PA6 GF30 (A1000F)

Other Details of PA6 GF30 (A1000F)

Physical Property

Ash

(15.0% 1 ISO3451/1)

Conditioned

600°C*2h

Density

(1250Kg/m3 1 ISO1183)

Conditioned

23°C

Shrinkage Parallel Flow

(0.5-0.7 % 1 ISO294-4)

Shrinkage Vertical Flow

(0.7-1.1% I ISO294-4)

Mechanical Properties

Tensile strength (125.0MPa 1 ISO527)

Conditioned

5mm/ min

Tensile Strain at Break (2.5% I ISO527)

Conditioned

1.0J

Notched Impact Strength (125 0MPa I ISO527)

Conditioned

2mm/min

Flexural Strength (190MPa 1ISO178)

Conditioned

2mm/min

Flexural Modulus (5700 MPa I ISO178)

Conditioned

5mm/ min

Thermal Property

Melting Point

(220°C I ISO11357)

Hot Deformation Temperature

(175*C I ISO75)

Conditioned

1.8MPa

Flammability Class

(HB 1UL94)

Conditioned

mm

Injection Molding Conditions

Drying Temperature

130°C

Drying Time

3h

Cylinder Temperature

240-260°C

Nozzle Temperature

240-260*C

Tooling Temperature

80*C

* Molding conditions are just for reference, please make an adjustment based on the actual situation!
